Ford F59
1
/
4
2026 Ford F59
In Stock
Visit our Store
- Joe Hall Ford
-
1617 21st Street
Lewiston, ID 83501
- Sales: 208-984-2490
- Service: 208-980-2941
- Parts: 208-793-5784
Vehicle Information
VIN:
1F65F5KN2T0A03290
Stock #:
26109
Model Code:
F5K
-
Body Style Commercial Stripped Chassis -
Engine 7.3L 2V DEVCT NA PFI V8 GAS Engine -
Transmission Automatic -
Fuel Type Gasoline
All Features
- Wheels (6) 19.5 Black
- I-Beam Axle Frt Suspension
- Springs - Taper Multi-Leaf
- Shock Absorbers - Sachs
- Stabilizer Bar, Front/Rear
- Steering - Power Trw Tas40
- Alternator - 210-Amp
- Battery 78-Amp-Hr 750-Cca
- Fuel Tank 40-Gallon
- Park Brake - Trans Mounted
- Neutral Idle
- Trailer Wire 7 Blunt Cut
- Fleet Telematics Modem
- Poat Coolant
- Headlamp Switch Assy
- Horn - Dual Electric
- Instrumentation
- - Coolant Temperature
- - Oil Pressure
- - Tachometer
- - Trip Odometer
- - Trans Temp Gauge
- - Indicator Lights
- Steering Wheel 17.5 Black
- - Tilt/ Telescope W/Cruise
- Brakes - Hydro-Boost
- - Power 4-Wheel Disc
- - 4-Wheel Anti-Lock
- - Anti-Lock 3 Channel
- - Traction Control
- Electronic Stability Cntrl
696A
ORDER CODE 696A
- Cold Cranking Amps @ 0° F (Primary): 750
- Cold Cranking Amps @ 0° F (2nd): 750
- Maximum Alternator Capacity (amps): 210
- Base Curb Weight (lbs): 5911
- Gross Axle Wt Rating - Front (lbs): 6500
- Gross Axle Wt Rating - Rear (lbs): 11000
- Curb Weight - Front (lbs): 3054
- Curb Weight - Rear (lbs): 2857
- Gross Vehicle Weight Rating Cap (lbs): 16000
- Gross Combined Wt Rating (lbs): 23000
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 7000
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 700
- Maximum Trailering Capacity (lbs): 7000
- Suspension Type - Front: Leaf
- Suspension Type - Rear: Leaf
- Spring Capacity - Front (lbs): 6500
- Spring Capacity - Rear (lbs): 11000
- Axle Type - Front: Non-Independent
- Axle Type - Rear: Rigid Axle
- Axle Capacity - Front (lbs): 6500
- Axle Capacity - Rear (lbs): 11000
- Axle Ratio (:1) - Front: 4.30
- Axle Ratio (:1) - Rear: 4.30
- Brake Type: 4-Wheel Disc
- Brake ABS System: 4-Wheel
- Brake ABS System (Second Line): 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 15
- Rear Brake Rotor Diam x Thickness (in): 15
- Front Tire Order Code: T91
- Rear Tire Order Code: T91
- Front Tire Size: LT225/70SR19.5
- Rear Tire Size: LT225/70SR19.5
- Front Tire Capacity (lbs): 7500
- Rear Tire Capacity (lbs): 15000
- Revolutions/Mile @ 45 mph - Front: 643
- Revolutions/Mile @ 45 mph - Rear: 643
- Front Wheel Size (in): 19.5 X 6
- Rear Wheel Size (in): 19.5 X 6
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Steering Type: Re-Circulating Ball
- Turning Diameter - Curb to Curb (ft): 45.4
- Fuel Tank Capacity, Approx (gal): 40
- Wheelbase (in): 158
- Length, Overall (in): 301.4
- Overhang, Front (in): 37.4
- Overhang, Rear w/o bumper (in): 106
- Passenger Capacity: 1
- Vehicle Name: Ford F-59 Commercial Stripped Chassis
- Body Style: Chassis
- Body Code: H
Warranty
- Ford Produced Chassis
- 3 Yr/36K Mile Bumper-To- Bumper Warranty
- 5Yr/60,000 Powertrain
- 5Yr/60,000 Roadside Assist
