• P235/75R15 all-terrain OWL tires
• 15" 7-spoke chrome-clad steel wheels
• Compact spare tire
• Raised "power dome" hood
• Body-color front/rear step bumper -inc: body-color painted face bar w/black lower front valance
• Front stone guards & rear mud flaps
• Chromed H-bar grille
• Fog lamps
• Bi-color tail lamps
• Black manual side mirrors
• Solar tinted glass -inc: windshield, front door windows & rear window
• Variable-intermittent windshield wipers
• Black door handles
• Quick-release tailgate w/black handle

• AM/FM stereo w/CD/MP3 player -inc: clock, satellite radio capability, audio input jack

• Air conditioning
• Cloth 60/40 split bench seat
• Rear vinyl jump seats
• Color-keyed carpeted floor covering & front floor mats
• Black urethane steering wheel
• Black-faced gauge cluster w/black trim rings
• SecuriLock anti-theft system
• Glove box
• Cup holders
• Smokers pkg -inc: lighter, ash tray
• 12-volt aux pwr point
• High series Ranger door trim panels -inc: cloth insert, map pockets
• Manual day/night rearview mirror
• Sun visors -inc: driver side strap, passenger side vanity mirror
• Driver/passenger A-pillar-mounted grab handles
• Dome light

• 4-wheel anti-lock brake system (ABS)
• Driver & front passenger dual-stage airbags -inc: front passenger sensing system
• Front shoulder safety belts -inc: height adjusters, pretensioners, energy management, retractors
• Center front lap belt
• Tire pressure monitoring system (TPMS)

4.0L SOHC V6 ENGINE

• (STD)

• Power Equipment Group: Power Windows/locks; Power Mirrors
• Order Code 867A: Cloth 60/40 Split Bench Seat; 3.73 Axle Ratio; 4.0L SOHC V6 Engine; AM/FM Stereo with MP3/satellite Capable CD; P235/75R15 OWL AT Tires; 15" 7-Spoke Chrome Clad Steel Wheels; 5-Speed Manual Transmission with Overdrive; 5
• 150 lbs Payload Package GVWR
• Leather-Wrapped Tilt Steering Wheel with Speed Control
• Cloth Sport Bucket Seats
• Sliding Rear Window
• Privacy Tinted Glass with Rear Quarters and Back
• 5
• 280 lbs Payload Package GVWR
• Cruise control with steering wheel mounted controls
• Select Drive part-time 4WD
• 4L V-6 regular gasoline
• engine with 207HP
• 4L V-6
• Mechanical
• SecuriLock(R) immobilizer
• Sliding rear windshield
• Front fog lights
• Leather steering wheel
• Manual tilting steering wheel
• Metallic paint
• Xxxxxx wheel covers
• 15 x 7-inch front and rear styled steel wheels
• P235/75SR15 AT OWL front and rear tires
• Cloth front seat upholstery
• 2 airbags
• Driver front impact airbag
• Passenger front impact airbag
• Airbag occupancy sensor
• Vinyl rear seat upholstery
• Manual climate control
• Transmission electronic control
• Reflector headlights
• Halogen headlights
• Driver seat with 4-way directional controls
• Front seat center armrest
• Front passenger seat with 4-way directional controls
• 4-wheel antilock (ABS) brakes
• Side facing rear seat
• Rear jump seats
• Fold-up rear seat cushion
• 50-50 folding rear seats
• Four-wheel drive
• Seating capacity: 4
• Trailer wiring harness
• Class III tow rating
• Trailer hitch
• Front beverage holders
• Front height adjustable seatbelts
• Front seatbelt pretensioners
• Basic warranty: 36 month/36
• 000 miles
• Rear splash guards
• AM/FM/satellite prep
• Power door mirrors
• Full-size spare tire with steel wheel
• Crank-down spare tire
• Passenger visor mirror
• Analog instrumentation display
• Low tire pressure warning
• Deep tinted windows

• Mileage
• Fuel Economy Est-Combined (MPG): 16
• EPA Fuel Economy Est - City (MPG): 15
• EPA Fuel Economy Est - Hwy (MPG): 19
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 540
• Maximum Alternator Capacity (amps): 115
• Maximum Alternator Watts: 1725
• Cooling System
• Total Cooling System Capacity (qts): 7.8
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2710
• Gross Axle Wt Rating - Rear (lbs): 2600
• Curb Weight - Front (lbs): 2193
• Curb Weight - Rear (lbs): 1520
• Gross Vehicle Weight Rating Cap (lbs): 5150
• Gross Combined Wt Rating (lbs): 7000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 200
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 3140
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 314
• Suspension
• Suspension Type - Front: SLA w/Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2710
• Spring Capacity - Rear (lbs): 2600
• Axle Type - Front: Twin-Forged SLA
• Axle Type - Rear: Ford Semi-Floating
• Axle Capacity - Front (lbs): 2850
• Axle Capacity - Rear (lbs): 2750
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): - TBD -
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.28 x 0.39
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 10.00 x 2.50
• Tires
• Front Tire Size: P235/75R15
• Rear Tire Size: P235/75R15
• Spare Tire Size: Compact
• Front Tire Capacity (lbs): 1843
• Rear Tire Capacity (lbs): 1843
• Spare Tire Capacity (lbs): 1984
• Revolutions/Mile @ 45 mph - Front: 717
• Revolutions/Mile @ 45 mph - Rear: 717
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 15 x 7
• Rear Wheel Size (in): 15 x 7
• Spare Wheel Size (in): Compact
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), On Center: 18.7
• Turning Diameter - Curb to Curb (ft): 43.0
• Turning Diameter - Wall to Wall (ft): 45.2
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 19.5
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 125.9
• Length, Overall w/o rear bumper (in): 203.6
• Width, Max w/o mirrors (in): 71.3
• Height, Overall (in): 67.7
• Overhang, Front (in): 34.0
• Overhang, Rear w/o bumper (in): 43.8
• Front Bumper to Back of Cab (in): 121.6
• Cab to Axle (in): 38.2
• Cab to End of Frame (in): 82
• Ground to Top of Load Floor (in): 31.9
• Frame Width, Rear (in): 32.8
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): 8.0
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 72.7
• Cargo Box Width @ Top, Rear (in): 54.4
• Cargo Box Width @ Floor (in): 54.4
• Cargo Box Width @ Wheelhousings (in): 40.5
• Cargo Box (Area) Height (in): 16.5
• Tailgate Width (in): 52.0
• Cargo Volume (ft³): 37.4
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 39.2
• Front Leg Room (in): 42.4
• Front Shoulder Room (in): 54.5
• Front Hip Room (in): 52.7
• Second Head Room (in): 33.2
• Second Leg Room (in): 39.1
• Second Shoulder Room (in): 14.1
• Second Hip Room (in): 18.7
• Summary
• Vehicle Name: Ford Ranger
• Body Style: Supercab 6' Styleside
• Body Code: 125.9" WB
• Emissions
• EPA Greenhouse Gas Score: 3
